High Precision
Planetary Gearboxes

APCK-Series High Precision Planetary Gearboxes

Be the first to review this product


$50.00

sku: apck

Availability: In stock



Quick Overview

The APCK Series is a high precision rotary flange style planetary gearbox in combination with a hypoid right angle gear. Less than 2 arc minute backlash. Case Hardened and ground gearing provide high accuracy and high wear resistance for the gear train. Compact structure provides high torsional rigidity, taper roller bearing support provides high axial and moment load capacity. NEW larger sizes available - APCK285 / APCK355 / APCK450.


Details

Output torque

  • T2N : Up to 10,900 Nm

Frame Sizes (mm)

  • 64/90/110/140/200/255/285/355/450

Ratios

  • AHK (2 Stage)
  • 12 / 15 / 16 / 20 / 25 / 28 / 35 / 40 / 49 / 50 / 70 / 100
  • AHKA (3 Stage)
  • 100 / 125 / 140 / 175 / 200 / 250 / 350 / 500 / 700 / 1,000
  • AHKB (3 Stage)
  • 64 / 84 / 100 / 125 / 140 / 175 / 200 / 250 / 280 / 350 / 400 / 500 / 700 / 1,000
  • AHK (4 Stage)
  • 1,225 / 1,400 / 1,750 / 2,000 / 2,800 / 3,500 / 5,000 / 7,000 / 10,000
  • AHKC
  • 2 Stage: 4 / 5 / 7 / 10
  • 3 Stage: 21 / 31 / 46 / 61 / 91

Lowest Backlash - High Wear Resistance

  • 2-stage : ≤2 arcmin (064 frame 3 arc min)
  • 3-stage : ≤2 arcmin
  • 4-stage : ≤2 arcmin

High Efficiency

  • 2-stage : ≧ 94%
  • 3-stage : ≧ 92%
  • 4-stage : ≧ 90%
  • 2-stage AHKC : ≧ 95%
  • 3-stage AHKC : ≧ 93%

Easy mount
Low Noise
Compact structure
