AP-Series High Precision Planetary Gearboxes
Only 0 left
SKU
AP
Views: 1944
$50.00
The AP Series is a high precision rotary flange style planetary gearbox with less than 1 arc minute backlash. Case Hardened and ground gearing provide high accuracy and high wear resistance for the gear train. The addition of a fourth planet gear increases torque capacity up to 29% Compact structure provides high torsional rigidity, taper roller bearing support provides high axial and moment load capacity. NEW larger sizes available - AP 285 / AP355 / AP450
Output torque
- T2N : Up to 13,875 Nm
Frame Sizes (mm)
- 110/140/200/255/285/355/450
Ratios
- 1-stage : 5.5
- 2-stage : 22 / 27.5 / 38.5 / 55
- 2-stage : 88 / 110 / 154 / 220
Lowest Backlash - High Wear Resistance
- 1 / 2 / 3-stage : ≤1 arcmin
High Efficiency
- 1-stage : ≧ 97%
- 2-stage : ≧ 94%
- 2-stage : ≧ 92%
Easy mount
Low Noise
Compact structure
